By Miles Nicholson Check out the new features in AutoCAD Electrical 2016 in the 2 videos below, the second one shows the then electro-mechanical workflow with Autodesk Inventor. What's New in AutoCAD Electrical 2016 - Part1 What's New in AutoCAD Electrical 2016 - Part2 The information below is from Location View Tab on Project Manager The new Location View tab on Project Manager provides a complete view of the devices and wiring contained in the active project. Components are organized by installation and location values. Once the projects are linked you can: • Link a component in AutoCAD Electrical with a part in Inventor using one of the following methods: • Insert from Catalog Browser. Performs a catalog lookup, using the catalog information from the Inventor part, where you can insert a symbol to link to the Inventor part.

• Link to Existing in Drawing. Select a symbol from the drawing to link to the Inventor part.

Default Wire Sequence The drawing and project property for sort order now applies to wire sequence as well as tag and wire number order. This setting provides default wire sequencing for wire networks with multiple components. AutoCAD Electrical performs the following steps when determining wire connection sequence: • Check for a wire sequence defined using the Edit Wire Sequence command, including any Direct-to-Terminal connections. • Check for angled tees on the wire network. • Check if any of the components have the same Location. • Use the Sort order drawing property to determine the connections for anything not accounted for in the previous checks.

E53 Manual Transmission. Discover the new 2018 version of AutoCAD Electrical, software for electrical design. Extract a list of electrical schematic components for panel layout drawings. Sep 26, 2015 Welcome to Electrical AutoCAD 2016 Tutorial 2. In Schematic Tab. Introduce the basic things about Ribbon Interface.

Schematic tab - Other Tools panel. And other custom devices or for converting existing non-AutoCAD Electrical symbols to make them “AutoCAD Electrical smart.”. Tips and Tricks. Pre-paid phone/e. On the Schematic tab of Electrical will act as a wizard and. Of a stock schematic symbol, AutoCAD® Electrical will find the.

Miscellaneous Enhancements • Child components linked directly to the parent with the dashed link line are filtered out of the cross-referencing on the parent component. • Buttons for rating defaults added to the View / Edit Rating Values dialog box when editing a panel component. Each button opens the Ratings default file so you can select a value to assign to the attribute. • The Insert Edit Component dialog box opens when you insert a parametric connector so you can further annotate the connector.

• The Copy Circuit command defaults to selecting multiple insertion points for creating multiple copies on the same drawing. • A new Circuit Builder API is available to link components within a circuit with a dashed link line. • The Export to Spreadsheet now freshens the database automatically before performing the export.
